New 2026 Jayco Eagle HT 294CKBS

Travel Trailer

Stock #17258

Mt. Vernon, WA - Sales

1 of 6

Specifications

Sleeps	4	Slides	3
Length	37 ft 11 in	Ext Width	8 ft 1 in
Ext Height	11 ft 11 in	Int Height	7 ft
Interior Color	Calli Linen	Hitch Weight	1290 lbs
GVWR	11700 lbs	Dry Weight	9660 lbs
Cargo Capacity	2040 lbs	Fresh Water Capacity	52 gals
Grey Water Capacity	74 gals	Black Water Capacity	37 gals
Tire Size	ST235/85R16'E	Furnace BTU	35000 btu
Available Beds	Olympic Queen	Refrigerator Type	12V
Refrigerator Size	10 cu ft	Cooktop Burners	3
Shower Size	30" x 36"	Number of Awnings	1
LP Tank Capacity	30 lbs	Water Heater Type	Tankless
AC BTU	15000 btu	TV Info	LR 4K Ultra LED HD Smart TV
Awning Info	14' Electric w/Integrated LED Lights	Axle Count	2
Washer/Dryer Available	Yes	Number of LP Tanks	2
Shower Type	Standard	Electrical Service	50 amp
VIN	1ujba0bt3t1c80074

Features

Standard Features (2026)

Exterior

5 in. fresh water drain valve
5 in. Magnum Truss™ with plywood roof decking
Alpha Ply TPO roof membrane (thickest roof membrane with limited lifetime warranty)
50-amp detachable power cord
LED lighting in pass-through area
Auto-grade vinyl graphics
Automotive-style front cap with max turn radius (painted on select models)
Black tank flush
Additional dump valve at termination
LED light and switch at termination
Climate Shield™ zero-degree tested weather protection:
- Fully enclosed and heated underbelly (ducted)
- 35K BTU furnace
- Double-layer fiberglass batt insulation in ceiling and floor
- Double-sided radiant barrier insulation (roof, floor, and behind cap)
- PEX plumbing
Commercial-grade rubber flooring in pass-through area (Fifth Wheels)
Dual 30 lb. LP bottles
Factory-installed roof ladder
Galvanized steel-coated outside kitchens
HELIX Cooling System™ (industry exclusive):
- Insulated dual duct design
- Directional and closeable A/C vents
- Larger return air vents with user-accessible filters
Independent satellite and cable hookups (outside kitchens and/or pass-through storage areas)
LED exterior lighting package
LP quick-connect for gas griddle (next to JayPort®)
Metal slam-latch baggage doors
Nautilus 2.5 water connections
Nitrogen-filled undermount spare tire (model/option varies: 15 in. or 16 in.)
Quick-connect water connections (door-side hot/cold and off-door side cold only)
Slide topper/awning prep
Stronghold VBL™ walls (laminated sidewalls, rear walls, and slide-out walls)
Rear camera prep
30 in. x 22 in. shower skylight

Interior Equipment

2-piece high-gloss bathroom surround
Teak seat shower prep
5/8 in. tongue-and-groove plywood flooring
75 lb. full-extension drawer guides
Bathroom skylight
Bedroom TV, SAT, and cable prep
P.A.P.-prepped bedroom (both sides)
Extra 120V power outlets in kitchen and slide rooms (where applicable)
Gas-strutted under-bed storage
High-sheen handcrafted door/drawer fronts (Fifth Wheels)
Handcrafted and glazed door/drawer fronts (Travel Trailers)
LED fireplace with 5K BTU electric space heater (select models) (Travel Trailers)
Matte black kitchen faucet with pull-out sprayer (Travel Trailers)
Medicine cabinet with custom-framed mirror
Kitchen faucet with pull-out sprayer (Fifth Wheels)
Porcelain foot-flush toilet
Residential vinyl flooring throughout (no carpet)
Theater seating (select models)
Tri-fold hide-a-bed sofa with residential memory foam sleep surface (select models)
USB-C 12V charging ports (multiple locations throughout)
Water shutoff at all faucet locations
NuvoH2O Water Treatment System (filters included)
100% no floor heat vents
4 in. interior ceiling fan lighting (4000K lumen)

Customer Value Package (Mandatory)

15K BTU "Whisper Quiet" A/C and bedroom A/C prep
4K Ultra LED HD Smart TV in living room
50-amp service with dual A/C ducts
60K on-demand tankless water heater
Custom-machined aluminum rims
Electric patio awning (integrated dimmable LED lights with JAYCOMMAND™)
Hidden hinges on cabinet doors
Interior & exterior "Blue Sync" Audio Connect with MB Quart sound (TV & phone)
Keyed-Alike™ lock system
MORryde Step Above™ entrance steps (main entrance)
Rain-proof bathroom power vent
Rear 2 in. towing receiver (4-pin connector on fifth wheels only)
Winegard Air 360 + antenna & router prep (NOW 5G)
Inverter pre-wire (multiple locations throughout)
Overlander I Solar Package (200W panel and 30-amp solar controller)

Luxury Package (Mandatory)

Blackout roller shades with reflective side throughout
Electric auto-leveling (Fifth Wheels)
GE 10 cu. ft. 12V refrigerator with black glass front
JayPort® 2 in. mount (for outside accessories)
Residential-style glass shower door
Washer/dryer prep (select models)
GE 30 in. over-the-range black and stainless microwave with exhaust fan
GE black and stainless 21 in. range with edge-to-edge grates
Inverter pre-wire (multiple locations throughout) (Travel Trailers)
Multi-function "All-in-One" black stainless steel kitchen sink
Residential 66 in. x 80 in. OLYMPIC size mattress
Magnetic catches for all drawers and doors
Solid surface kitchen countertop(s)
LED fireplace with 5K BTU electric space heater (select models)
JAYCOMMAND™ with monitor switch panel
Exterior light and outlet at the JayPort® location

4 Star Handling Package (Mandatory)

Dexter® axles with NEV-R-Adjust® brakes and E-Z Lube® hubs
15 in. "E" rated tires or 16 in. "H" rated tires (Fifth Wheels)
Rainer "E"-rated tires or Rainier "H"-rated tires
MORryde® CRE-3000™ rubberized suspension
Wet bolt fasteners with bronze bushings

Options (Fifth Wheels)

5K BTU bedroom A/C
HALO™ 22 in. outside griddle with deep sink attachment for JayPort® system
Booth dinette (select models)
Dry camping package (generator prep; extra LP capacity)
Extreme Weather Package with 120 heat pads and 12V heat tape on freshwater line
Free-standing table with leaf, two chairs, and bench seat
Overlander II Solar Package: (2) 200W panels, MPPT 30-amp solar controller, and 1800W inverter
Theater seating in place of tri-fold sofa (select models)
Furniture cup holder tables (1 pair)
Dexter® ABS brake system with anti-sway
Triple reclining sofa in place of dinette (select models)
SpartanLync™ TPMS

Options (Travel Trailers)

15K BTU bedroom A/C
HALO™ 22 in. outside griddle with deep sink attachment for JayPort® system
Booth dinette (select models)
Extreme Weather Package with 120 heat pads and 12V heat tape on freshwater line
Frameless dual-pane windows
Free-standing table with leaf, (2) chairs, and bench seat
Overlander 2 Solar Package: (2) 200W panels, MPPT 30-amp solar controller, and 1800W inverter
Residential 72 in. x 80 in. king-size mattress (select models)
Theater seating in place of tri-fold sofa (select models)
Furniture cupholder tables (1 pair)
Dexter® ABS brake system with anti-sway
Triple-reclining sofa in place of dinette (select models)
SpartanLync™ TPMS monitoring
Electric auto-leveling

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Due to the current environment, our features and options are subject to change due to material availability.

Favorite RVs

Save your favorite RVs as you browse. Begin with this one!

Extremely satisfied
Thank you to the entire team at Blade RV!!! We were extremely satisfied with the sales and service we experienced with our recent purchase of our travel trailer. We were Johns first customers and he did a great job with support from Robin. They were both very fun to work with. The service group lead

Mondau
Couldn't be happier!
I can't thank Brett enough for all his patience with us over the last 3 years while we tried to decide if we wanted to buy a Jayco Class C or keep trailering. Every time we stopped to look at Class C's Brett was always very friendly, never pressured us and so very knowledgeable about the Jayco product.

Jack
Great experience!
We would like to thank the entire staff at Blade RV! We were extremely satisfied with the sales and service we experienced with our recent purchase of our travel trailer. John work with us all afternoon til we decided on the 308rets. He did a great job for us along with Robin. They were both very fun

Dennis

We are here to help, call us at
360-707-7990 or Contact Us

We are here to help!

Blade RV Center is not responsible for any misprints, typos, or errors found in our website pages. Any price listed excludes sales tax, registration tags, and delivery fees. Manufacturer pictures, specifications, and features may be used in place of actual units on our lot. Please contact us @360-707-7990 for availability as our inventory changes rapidly. All calculated payments are an estimate only and do not constitute a commitment that financing or a specific interest rate or term is available.

New 2026 Jayco Eagle HT 294CKBS

294CKBS Floorplan
